Corrosorber® VpCI® Paper

Corrosorber® VpCI® Paper

PRODUCT DESCRIPTION:

Corrosorber® VpCI® Paper is a tarnish inhibiting packaging paper specifically for precious metals such as silver, gold, and tin. Corrosorber® VpCI® Paper is a unique product; one side of the paper has a special coating that scavenges or seeks out H2S gas.

Service Hotline:
+86-0532-80989502,+86-135-0535-2885
E-Mail:zzgvci@163.com

When a significant amount of H2S gas has been absorbed by the paper, the paper will change from light green to a darker color. On the other side of Corrosorber® VpCI® Paper is a corrosion inhibitor that will protect precious metals for up to two years or until the opposite side of the paper has significantly darkened. Corrosorber® VpCI® Paper will eliminate the need for coatings and tarnish removers that are often associated with precious metals. With Corrosorber® VpCI® Paper, you can rest assured that your valuable precious metals will have the same appearance as prior to packaging. Corrosorber® VpCI® Paper will in no way affect further processing of the precious metal or affect physical properties such as conductivity or surface resistivity


FEATURES:

• Contains hydrogen sulfide scavenger and saturation indicator
• Effective against aggressive environments including humidity, SO2, H2S, and galvanic corrosion from dissimilar metals
Combines protection from tarnish and packaging into one step
• Worker safe: contains no nitrites, phosphates, silicones, chromates, or other heavy metals

APPLICATION:

Corrosorber® VpCI® Paper can be used to protect products for storage and shipment  in a wide variety of ways. Use Corrosorber® VpCI® Paper for single or multiple item packaging
• Electrical components, controls, etc.
• Jewelry and other finished goods
• Precious metal shipping container linings
• Silver solder wire
Corrosorber® VpCI® Paper is a multicolored paper. One side is white and the other is green. When packaging, face the white side of the paper toward the metal. The opposite side of the paper, which is green, will then absorb contaminants, thus preventing them from reaching the surface of the metal.
Corrosorber® VpCI® Paper is simple to use. Products should be packaged as soon after cleaning as possible, but completely dried of residual water. Keep Corrosorber® VpCI® Paper as near the surface of the product as is practical, leaving no barrier between the Corrosorber® VpCI® Paper and the metal surface. Wrap the paper around your precious metals and fold the edges of the paper together so there is no free airflow. Corrosorber® VpCI® Paper can also be used as insert strips for recessed areas in large packages, as sheet liners, or as separators between products. The VpCI® coating on the paper will vaporize, reaching all metal surfaces to provide complete corrosion inhibition. Many tarnish inhibitors need to removed after use, but with Corrosorber®VpCI® Paper there is no removal needed of the inhibitor.



Hydrogen Sulfide Cycling Test Results:

H2S Concentrate
Sample Result
Unprotected Silver Heavy tarnish
Silver Protected with Corrosorber®VpCI® Paper No visible tarnish


TYPICAL PROPERTIES:

Method Unit Corrosorber®VpCI®Paper
Basis  Weight T-410 lbs/3000 ft2 (g/m2) 40(60)
Caliper (thickness) T-411 mils (um)
3.35 (85)
Tear - MD T-411 grams 48
Tear- CD T-411 grams 41
Puncture  Resistance
ASTM D3420-45B grams 195
